KT-4M110PA Four Post Alignment Lift 11,000lbs with 7,000lb Rolling Jack
$5,100.00
*Concrete must be at least 5.9” (150 mm) thick with a 3000 PSI rating. Installing this lift on improper concrete could result in serious injury or death! It is the customer’s responsibility to verify concrete thickness and strength before purchase and installation.
A commercial-grade 4-post alignment lift built for repair shops – and it comes with a 7,000 lb rolling jack included, so you can lift the wheels off the runways for brake, suspension and tire work.
- 11,000 lb lifting capacity.
- Alignment-ready runways for wheel alignment work.
- 7,000 lb rolling jack included.
- Single-point pneumatic safety lock release – release all four locks with one lever (requires shop air).
- Four mechanical locking devices, plus a secondary slack-cable safety system that engages in the unlikely event of cable failure.
- Non-skid diamond-plate runways and adjustable safety lock ladders.
- Comes with drip trays, a lift tray, casters and approach ramps.
- Customer must have a forklift for unloading (not needed if you choose Equipment + Installation).
- Hydraulic power unit: 110V/60Hz/1PH.
| Lifting Capacity | 11,000 lbs (4,990 kg) |
| Max. Lifting Height | 84.5" |
| Height of Posts | 94.88" / 2,410 mm |
| Width Overall | 126" / 3,200 mm |
| Length Overall | 229.73" / 5,835 mm (with ramps) |
| Inside Columns | 112.81" / 2,865 mm |
| Min. Runway Height | 6.2" / 157 mm |
| Lock Release | Pneumatic, single point |
| Net Weight | 2,116 lbs / 960 kg |
| Power | 110V/60Hz/1PH |
Delivery & Professional Installation
- Professional installation by our own team – choose “Equipment + Installation” above.
- Hydraulic fluid is included with installation. Have your own? Choose “I’ll supply my own” and save $70. Equipment-only orders do not include fluid.
- Free local delivery within 60 miles of our Pensacola shop. A travel charge applies from 60–100 miles and is shown at checkout.
- Pickup available at 3715 W Navy Blvd, Pensacola, FL 32507.
- Pick your delivery, installation, or pickup day at checkout.
- More than 100 miles away? Request a custom quote and we’ll send you a checkout link.
